PROSAFE 500 AP WLS CONTROLLER
OVERVIEW
High Capacity Enterprise-Class Wireless Controller
The WC9500 High Capacity Wireless Controller is ideal for education customers, medium to large sized hospitality, and healthcare deployments. Designed with simplicity in management and ease of use, it offers enterprise grade functionality and capacity for organizations of all sizes.
NETGEAR Warranty
- This product is backed by a NETGEAR ProSAFE® Lifetime Hardware Warranty. Click here ( <> ) for coverage, availability and terms and conditions.
- Lifetime Next Business Day Hardware Replacement. Click here ( <> ) for coverage, availability and terms and conditions.
- ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.
- ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat. (Remote diagnostics performed by our technical experts for prompt resolution of technical issues).
TECH SPECS
WC9500
Physical Characteristics
Power
- 165 watts with internal dual power supply
- 100-240V AC Universal
- IEC 320 connector
Physical Dimensions (1 RU)
- Dimensions (L x W x H): 440 x 430 x 43 mm
Weight
- 1 PSU: 6.32 kg
- 2 PSU: 7.57 kg
Environmental Conditions
Operating Temperature
- Minimum (C) 0°
- Maximum (C) 45°
Storage Temperature
- Minimum (C) -20°
- Maximum (C) 70°
Operating Relative Humidity
Storage Humidity
MTBF
- WC9500 (@25C): 664,072 hours
- Fan Tray (@25C): 676,058 hours
- Power Supply (@25C): 938,490 hours
Power Consumption
- Maximum: 82.3W or 281 BTU/hr
Compliance
- ENGR 10049 EST Environmental Stress Test Guideline
- ENGR 10045 EVT Engineering Validation Test Guideline
- ENGR 10048 CVT Compliance Validation Test Guideline
- ENGR 10046 SVT System Validation Test Guideline
- ENGR 10023 HALT Highly Accelerated Life Test Guideline
- ENGR 10036 CDG Component Derating Guideline
Capacity
Managed APs
Controllers per Cluster
WLANs (BSSIDs)
Concurrent Stations
- 36,000 per cluster
- 12,000 per controller
Guest Portal
Profile Groups per Controller
Profile per Controller
Security Profile Groups per Profile Group
Detectable rogue AP
Features
- Layer 2 Discovery
- Layer 3 Discovery
- L2 Roaming
- L3 Roaming
- Layer 2 isolation
- Access List
- Auto Channel Allocation
- Radius, AD, and LDAP proxy
- Remote AP
- Client load balancing
- Auto Power Control
- Coverage Hole Detection
- Rate Limiting on per SSID
- Rate Limiting on per client
- 802.11e WMM
- Schedule AP on/of
- Captive Portal
- Stacking Redundancy (N+1)
Interfaces and Indicators
10G SFP+ Ports for Data and Control
- Two 1/10Gbps auto-sensing and auto-negotiation
1G Copper RJ-45 Ports for Management
- One 10/100/1000 Mbps auto-sensing and auto-negotiation
USB Ports
- One USB 2.0 Type A connector
Console
- One 1 D-Sub-9 MALE connector
LED
- Power, status, fan, stacking master
Default Reset
Networking
IP
VLANs
Redundancy
Stacking
- Maximum: Three controllers per stack
DHCP Server
Management
Configuration
- Web user interface
- SNMPv1
- SNMPv2
AAA
- Radius (primary and backup)
AP Provisioning
Wireless Security Standards
Encryption
Authentication
Access Control
Supported APs
- WNDAP660
- WNDAP620
- WNDAP360
- WNDAP350
- WN370
- WNAP320
- WNAP210v2
- WNDAP380Rv2 (China only)
- WND930
Supported Modes
Main Functionality
Product Ordering Information
- WC9500-1000PRS
- WC9500-10000S
